12 Volt 200psi Double Ended Air Compressor 4.2L 200 Psi Steel Air Tank Pro-Max Series Universal Full System
As low as $688.00
A universal complete air system with one 12 Volt 200psi Double Ended Air Compressor, one 4 Litre 200psi Air Tank Pro-Max Series and other accessories included
In stock
SKU
AOBFS48P42
Compressor Test Result
Test Conditions
- All tested direct from battery with vehicle running
- charge voltage of 13.7
- All running directly to tank with 700 mm leader hose
- ARB single and twin doesn't run a oneway valve it just relies on the reed
- ARB single and twin come with 70 to 100 psi pressure switch
- ARB single and twin comes with own wiring loom and carling type switch
- ARB single and twin have built in pressure relief valves into head assembly
- ARB single and twin have max running pressure of 150 psi
AOB Complete Air System With 12 Volt 200 Psi Double Ended Air Compressor & 4.2L 200 Psi Steel Air Tank Pro-Max Series
AOB Air Compressor Kit Install Into A 200-series LandCruiser YOUTUBE VIDEO
This system comes with all the following items:
- ''Air On Boards'' 12V 200psi AOBCM480D compressor
- 4.2 litre tank Pro-Max Series rated at 200psi
- 150cm High Temp Steel Braided Air Hose
- 3 meter Low Temp High Pressure Air Hose
- Manifold Set
- Rubber bush compressor mount
- Full wiring kit
- Instruction Manual
It can be used to fill tires, run Air jacks, pump up mattresses and inflatable boats in good time, run your air lockers, air bags and train horns, even run small Pneumatic air tools all from your 4WD or car.
- 12 Volt DC
- Duty cycle: 100% at 100psi
- Max working pressure: 200 psi
AOBCM480D COMPRESSOR
This 12 volt compressor has A full Steel body. With a maximum output of 200 Psi and a duty cycle of 100% at 72 deg F&100 psi it will provide you with enough air for all your needs.
- 12-Volt
- Permanent Magnetic Motor
- Duty Cycle: 100% @ 100 PSI
- Max. Working Pressure: 200 PSI
- Max. Air Tank Size: 2.5 gallon
- Ingress Protection Rating: IP67
- Dimensions: 355mm(L) x 90mm(W) x 160mm(H)
- Net Weight: 6.4KG
AOBTKP042
- 4.2 Litre Air Tank
- 200 psi max working pressure
- 5 Ports fit 5 x 1/4 BSP Female Fittings with
- 2 x each end
- 1x Centre (for drain tap)
- 2 x Mounting Brackets + Bolts supplied with the tank
- Weight: 4.3kg
- Material: Steel
AOBTKP042 Dimensions
100mm diameter; 600mm long
Ensure you have the room to fit this tank.
AOBMB770 MANIFOLD SET
Included with this system are all the air accessories needed for your system in this neat manifold block. Makes for easy installation.
AOBHS201 High Temp Steel Braided Air Hose
- OD of hose is 8.8mm.
- 1/4'' BSP male fitting both ends.
- Temperature range of -40°C to 250°C.
- Excellent flexibility.
- Pressure range to 350 PSI.
- 150cm in length.
AOB Low Temp High Pressure Air Hose
- OD of hose is 14mm.
- ID of hose is 10mm.
- Pressure range to 200 PSI.
- 3 meter in length.
WIRING KIT
Everything you need to install and wire this compressor is include in the sale price. Don't get court by buying 12 volt compressors with out the CORRECT wiring kit. By buying it all included you can be assured that you will receive the correct size fuses, relays, switches and wire.
- 100 mm black earth cable.
- 12 volt 30 amp relay.
- 3mtr 4mm power cable.
- 3mtr 3mm power cable.
- low amp fuse holder.
- High amp fuse holder.
- 12 volt toggle switch.
- All connectors, pre-wired ready to install .
RUBBER MOUNT
The compressor is supplied with rubber vibration pads to protect the compressor from excessive vibration.
It is not recommended to mount any 12 volt compressor up side down. Whilst it will still run mounted in this position, the problem is caused by the heat generated by the compressor not escaping correctly and radiating back through the compressor body into the windings. This causing damage to the motor and premature failure of the compressor.
| Comp Max Pressure | 200Psi |
|---|---|
| Horn | Without Horn |
| Tank | 4 Litre |
